The H4 looks and surfs differently from any other fin. Precision Swiss engineering matched with a highly evolved template provides an unprecedented level of control and predictability at high speeds.

Free shipping on this item

• Performance
• Material
• Size

• Overview

  UNIQUE TEMPLATE

  Radically different side & centre fin templates create a powerful fin set with ultimate speed & drive.

  • SIDE FIN PROFILE: The lower section produces maximum acceleration, while the hatchet like tip creates stability & control.
  • CENTRE FIN PROFILE: Highly raked elliptical outline reduces drag, and offers a feeling of predictability when releasing through turns.
  • FIN FOILS TEMPLATE: Thicker base with tapered tip optimises flex & regulates the release of energy during rail-to-rial transitions.




  Ideal Conditions

  • A wide range of conditions, particularly good in critical overhead waves.




  Board Types

  • Designed to fit the FCS II Fin System.
  • Recommended for performance shortboards with moderate-to-low rocker.




  Fin Family

  • Accelerator: Find Control. Speed, flow and response with added control.








• NEW CONSTRUCTION

  • PRECISION SWISS ENGINEERED: Creates perfect synergy between fin geometry & HI-FI materials, giving a smooth & predictable feel.
  • HIGH-DENSITY UNI-DIRECTIONAL CARBON FIBRE: Light & super strong with custom orientation to transfer more of your energy into speed than any other fin.
  • DYNAMIC TRAILING EDGE: Internal composite morphs under extreme load, enabling the fins to be pushed harder without sliding out.
  • INNOVATIVE PRODUCTION: Highly specialised robotic automation combined with camera-assisted quality control, ensures absolute accuracy.

  DISCLAIMER:

  • The FCSII H4 Fins are used in conjunction with a sport that is considered dangerous. The manufacturer and retailer assume no responsibility for injuries to persons or property caused by use, misuse or inability to use this product.

  GUARANTEE:

  • This product is fully guaranteed against faulty workmanship and materials for 1 year.



• SMALL (55Kg - 70Kg / 120 - 155 Lbs)
  MEDIUM (65Kg - 80Kg / 145 - 175 Lbs)
  LARGE (75Kg - 90Kg / 165 - 200 Lbs)



  Fin	Base (inches)	Base (mm)	Depth (inches)	Depth (mm)	Area (inches)	Area  (mm)	Sweep Deg°	Foil
  SML Side	4.36	110.6	4.34	110.1	14.29	9221	38.3°	Flat
  SML Ctr	4.29	108.8	4.49	113.9	13.82	8917	37.2°	50/50
  MED Side	4.48	113.6	4.45	113.0	15.07	9721	38.3°	Flat
  MED Ctr	4.40	111.7	4.61	117.0	14.58	9405	37.2°	50/50
  LRG Side	4.59	116.5	4.57	115.9	15.84	10221	38.3°	Flat
  LRG Ctr	4.52	114.6	4.73	120.0	15.33	9893	37.2°	50/50

  View the FCS Fin Data page for Base/Depth/Area/Foil information.




•
